I have had a "new year's resolution" post in draft for more than two months… since we now reached march, I have wasted it – not much point anymore posting it.
One thing that was NOT written in that post but that did work out, tho: I smoked one last cigarette on the 31st of december and I decided to quit smoking. So far so good.
I also have a draft of a technical post sitting there for a long time… I'll eventually finish it at one stage.
I thought I'd post a picture of my beautiful little girl, instead, in the meantime.

The following technique should already be understood by any powersheller. Here we focus on Operations Manager log entries, even if the data mining technique shows is entirely possibly – and encouraged – with any other event log.

Let’s start by getting our eventlog into a variable called $evt:

PS  >> $evt = Get-Eventlog “Operations Manager”

The above only works locally in POSH v1.

In POSH v2 you can go remotely by using the “-computername” parameter:

PS  >> $evt = Get-Eventlog “Operations Manager” –computername RMS.domain.com

Anyhow, you can get to this remotely also in POSHv1 with this other more “dotNET-tish” syntax:

PS >> $evt = (New-Object System.Diagnostics.Eventlog -ArgumentList "Operations Manager").get_Entries()

you could even export this (or any of the above) to a CLIXML file:

PS >> (New-Object System.Diagnostics.Eventlog -ArgumentList "Operations Manager").get_Entries() | export-clixml -path c:\evt\Evt-OpsMgr-RMS.MYDOMAIN.COM.xml

and then you could reload your eventlog to another machine:

PS  >> $evt = import-clixml c:\evt\Evt-OpsMgr-RMS.MYDOMAIN.COM.xml

whatever way you used to populate your $evt  variable, be it from a “live” eventlog or by re-importing it from XML, you can then start analyzing it:

PS  >> $evt | where {$_.Entrytype -match "Error"} | select EventId,Source,Message | group eventid

Count Name                      Group
—– —-                      —–
1510 4509                      {@{EventID=4509; Source=HealthService; Message=The constructor for the managed module type "Microsoft.EnterpriseManagement.Mom.DatabaseQueryModules.GroupCalculatio.
   15 20022                     {@{EventID=20022; Source=OpsMgr Connector; Message=The health service {7B0E947B-2055…
    3 26319                     {@{EventID=26319; Source=OpsMgr SDK Service; Message=An exception was thrown while p…
    1 4512                      {@{EventID=4512; Source=HealthService; Message=Converting data batch to XML failed w…

the above is functionally identical to the following:

PS  >> $evt | where {$_.Entrytype -eq 1} | select EventID,Source,Message | group eventid

Count Name                      Group
—– —-                      —–
1510 4509                      {@{EventID=4509; Source=HealthService; Message=The constructor for the managed modul…
   15 20022                     {@{EventID=20022; Source=OpsMgr Connector; Message=The health service {7B0E947B-2055…
    3 26319                     {@{EventID=26319; Source=OpsMgr SDK Service; Message=An exception was thrown while p…
    1 4512                      {@{EventID=4512; Source=HealthService; Message=Converting data batch to XML failed w…

Note that Eventlog Entries’ type is an ENUM that has values of 0,1,2 – similarly to OpsMgr health states – but beware that their order is not the same, as shown in the following table:

Let’s now look at Information Events (Entrytype –eq 0)

PS  >> $evt | where {$_.Entrytype -eq 0} | select EventID,Source,Message | group eventid

Count Name                      Group
—– —-                      —–
4135 2110                      {@{EventID=2110; Source=HealthService; Message=Health Service successfully transferr…
1548 21025                     {@{EventID=21025; Source=OpsMgr Connector; Message=OpsMgr has received new configura…
4644 7026                      {@{EventID=7026; Source=HealthService; Message=The Health Service successfully logge…
1548 7023                      {@{EventID=7023; Source=HealthService; Message=The Health Service has downloaded sec…
1548 7025                      {@{EventID=7025; Source=HealthService; Message=The Health Service has authorized all…
1548 7024                      {@{EventID=7024; Source=HealthService; Message=The Health Service successfully logge…
1548 7028                      {@{EventID=7028; Source=HealthService; Message=All RunAs accounts for management gro…
   16 20021                     {@{EventID=20021; Source=OpsMgr Connector; Message=The health service {7B0E947B-2055…
   13 7019                      {@{EventID=7019; Source=HealthService; Message=The Health Service has validated all …
    4 4002                      {@{EventID=4002; Source=Health Service Script; Message=Microsoft.Windows.Server.Logi…

And “Warning” events (Entrytype –eq 2):

PS  >> $evt | where {$_.Entrytype -eq 2} | select EventID,Source,Message | group eventid

Count Name                      Group
—– —-                      —–
1511 1103                      {@{EventID=1103; Source=HealthService; Message=Summary: 1 rule(s)/monitor(s) failed …
  501 20058                     {@{EventID=20058; Source=OpsMgr Connector; Message=The Root Connector has received b…
    5 29202                     {@{EventID=29202; Source=OpsMgr Config Service; Message=OpsMgr Config Service could …
  421 31501                     {@{EventID=31501; Source=Health Service Modules; Message=No primary recipients were …
   18 10103                     {@{EventID=10103; Source=Health Service Modules; Message=In PerfDataSource, could no…
    1 29105                     {@{EventID=29105; Source=OpsMgr Config Service; Message=The request for management p…

Ok now let’s see those event 20022, for example… so we get an idea of which healthservices they are referring to (20022 indicates" “hearthbeat failure”, btw):

PS  >> $evt | where {$_.eventid -eq 20022} | select message

Message
——-
The health service {7B0E947B-2055-C12A-B6DB-DD6B311ADF39} running on host webapp3.domain1.mydomain.com and s…
The health service {E3B3CCAA-E797-4F08-860F-47558B3DA477} running on host SERVER1.domain2.mydomain.com and serving…
The health service {E3B3CCAA-E797-4F08-860F-47558B3DA477} running on host SERVER1.domain2.mydomain.com and serving…
The health service {E3B3CCAA-E797-4F08-860F-47558B3DA477} running on host SERVER1.domain2.mydomain.com and serving…
The health service {52E16F9C-EB1A-9FAF-5B9C-1AA9C8BC28E3} running on host DC4WK3.domain1.mydomain.com and se…
The health service {F96CC9E6-2EC4-7E63-EE5A-FF9286031C50} running on host VWEBDL2.domain1.mydomain.com and s…
The health service {71987EE0-909A-8465-C32D-05F315C301CC} running on host VDEVWEBPROBE2.domain2.mydomain.com….
The health service {BAF6716E-54A7-DF68-ABCB-B1101EDB2506} running on host XP2SMS002.domain2.mydomain.com and serving mana…
The health service {30C81387-D5E0-32D6-C3A3-C649F1CF66F1} running on host stgweb3.domain3.mydomain.com and…
The health service {3DCDD330-BBBB-B8E8-4FED-EF163B27DE0A} running on host VWEBDL1.domain1.mydomain.com and s…
The health service {13A47552-2693-E774-4F87-87DF68B2F0C0} running on host DC2.domain4.mydomain.com and …
The health service {920BF9A8-C315-3064-A5AA-A92AA270529C} running on host FSCLU2 and serving management group Pr…
The health service {FAA3C2B5-C162-C742-786F-F3F8DC8CAC2F} running on host WEBAPP4.domain1.mydomain.com and s…
The health service {3DCDD330-BBBB-B8E8-4FED-EF163B27DE0A} running on host WEBDL1.domain1.mydomain.com and s…
The health service {3DCDD330-BBBB-B8E8-4FED-EF163B27DE0A} running on host WEBDL1.domain1.mydomain.com and s…

or let’s look at some warning for the Config Service:

PS  >> $evt | where {$_.Eventid -eq 29202}

   Index Time          EntryType   Source                 InstanceID Message
   —– —-          ———   ——                 ———- ——-
5535065 Dec 07 21:18  Warning     OpsMgr Config Ser…   2147512850 OpsMgr Config Service could not retrieve a cons…
5543960 Dec 09 16:39  Warning     OpsMgr Config Ser…   2147512850 OpsMgr Config Service could not retrieve a cons…
5545536 Dec 10 01:06  Warning     OpsMgr Config Ser…   2147512850 OpsMgr Config Service could not retrieve a cons…
5553119 Dec 11 08:24  Warning     OpsMgr Config Ser…   2147512850 OpsMgr Config Service could not retrieve a cons…
5555677 Dec 11 10:34  Warning     OpsMgr Config Ser…   2147512850 OpsMgr Config Service could not retrieve a cons…

Once seen those, can you remember of any particular load you had on those days that justifies the instance space changing so quickly that the Config Service couldn’t keep up?

Or let’s group those events with ID 21025 by hour, so we know how many Config recalculations we’ve had (which, if many, might indicate Config Churn):

PS  >> $evt | where {$_.Eventid -eq 21025} | select TimeGenerated | % {$_.TimeGenerated.ToShortDateString()} | group

Count Name                      Group
—– —-                      —–
   39 12/7/2009                 {12/7/2009, 12/7/2009, 12/7/2009, 12/7/2009…}
  203 12/8/2009                 {12/8/2009, 12/8/2009, 12/8/2009, 12/8/2009…}
  217 12/9/2009                 {12/9/2009, 12/9/2009, 12/9/2009, 12/9/2009…}
  278 12/10/2009                {12/10/2009, 12/10/2009, 12/10/2009, 12/10/2009…}
  259 12/11/2009                {12/11/2009, 12/11/2009, 12/11/2009, 12/11/2009…}
  224 12/12/2009                {12/12/2009, 12/12/2009, 12/12/2009, 12/12/2009…}
  237 12/13/2009                {12/13/2009, 12/13/2009, 12/13/2009, 12/13/2009…}
   91 12/14/2009                {12/14/2009, 12/14/2009, 12/14/2009, 12/14/2009…}

Event ID 21025 shows that there is a new configuration for the Management Group.

Event ID 29103 has a similar wording, but shows that there is a new configuration for a given Healthservice. These should normally be many more events, unless your only health Service is the RMS, which is unlikely…

If we look at the event description (“message”) in search for the name (or even the GUID, as both are present) or our RMS, as follows, then they should be the same numbers of the 21025 above:

PS  >> $evt | where {$_.Eventid -eq 29103} | where {$_.message -match "myrms.domain.com"} | select TimeGenerated | % {$_.TimeGenerated.ToShortDateString()} | group

Count Name                      Group
—– —-                      —–
   39 12/7/2009                 {12/7/2009, 12/7/2009, 12/7/2009, 12/7/2009…}
  203 12/8/2009                 {12/8/2009, 12/8/2009, 12/8/2009, 12/8/2009…}
  217 12/9/2009                 {12/9/2009, 12/9/2009, 12/9/2009, 12/9/2009…}
  278 12/10/2009                {12/10/2009, 12/10/2009, 12/10/2009, 12/10/2009…}
  259 12/11/2009                {12/11/2009, 12/11/2009, 12/11/2009, 12/11/2009…}
  224 12/12/2009                {12/12/2009, 12/12/2009, 12/12/2009, 12/12/2009…}
  237 12/13/2009                {12/13/2009, 12/13/2009, 12/13/2009, 12/13/2009…}
   91 12/14/2009                {12/14/2009, 12/14/2009, 12/14/2009, 12/14/2009…}

Going back to the initial counts of events by their IDs, when showing the errors the counts above had spotted the presence of a lonely 4512 event, which might have gone undetected if just browsing the eventlog with the GUI, since it only occurred once.

Let’s take a look at it:

PS  >> $evt | where {$_.eventid -eq 4512}

   Index Time          EntryType   Source                 InstanceID Message
   —– —-          ———   ——                 ———- ——-
5560756 Dec 12 11:18  Error       HealthService          3221229984 Converting data batch to XML failed with error …

Now, when it is about counts, Powershell is great.  But sometimes Powershell makes it difficult to actually READ the (long) event messages (descriptions) in the console. For example, our event ID 4512 is difficult to read in its entirety and gets truncated with trailing dots…

we can of course increase the window size and/or selecting only THAT one field to read it better:

PS  >> $evt | where {$_.eventid -eq 4512} | select message

Message
——-
Converting data batch to XML failed with error "Not enough storage is available to complete this operation." (0×8007000E) in rule "Microsoft.SystemCenter.ConfigurationService.CollectionRule.Event.ConfigurationChanged" running for instance "RMS.MYDOMAIN.COM" with id:"{04F4ADED-2C7F-92EF-D620-9AF9685F736F}" in management group "SCOMPROD"

Or, worst case, if it still does not fit, we can still go and search for it in the actual, usual eventlog application… but at least we will have spotted it!

The above wants to give you an idea of what is easily accomplished with some simple one-liners, and how it can be a useful aid in analyzing/digging into Eventlogs.

All of the above is ALSO be possible with Logparser, and it would actually be even less heavy on memory usage and it will be quicker, to be honest!

I just like Powershell syntax a lot more, and its ubiquity, which makes it a better option for me. Your mileage may vary, of course.

So I was testing other stuff tonight, to be honest, but I got pinged on Instant Messenger by my geek friend and colleague Stefan Stranger who pointed me at his request for help here http://friendfeed.com/sstranger/4571f39b/help-needed-on-winrs-or-winrm-and-openwsman-to

He wanted to use WINRM or any other command line utility to interact with the Xplat agent, and call methods on the Unix machine from windows. This could be very useful to – for example – restart a service (in fact it is what the RECOVERY actions in the Xplat Management Packs do, btw).

At first I told him I had only tested enumerations – such as on this other post http://www.muscetta.com/2009/06/01/using-the-scx-agent-with-wsman-from-powershell-v2/ … but the question intrigued me, so I check out the help for winrm’s INVOKE verb:

Which told me that you can pass in the parameters for the method to be called/invoked either as an hashtable @{KEY=”value”;KEY2=”value”}, or as an input XML file. I first tried the XML file but I could not get its format right.

After a few more minutes of trying, I figured out the right syntax.

This one works, for example:

winrm invoke ExecuteCommand http://schemas.microsoft.com/wbem/wscim/1/cim-schema/2/SCX_OperatingSystem?__cimnamespace=root/scx @{command="ps";timeout="60"} -username:root -password:password -auth:basic -r:https://virtubuntu.huis.dom:1270/wsman -skipCACheck -encoding:UTF-8

Happy remote management of your unix systems from Windows

Sara, my granny, is very old, and very sick.
I was afraid she wouldn't even have lived long enough to meet Sara, my daughter.

She has Alzheimer, Osteoporosis, and a million other diseases; She had a heart attack two months ago, then another one, and also a stroke. She can't walk anymore, she can't see much anymore, her whole body is giving up. The doctors now say that she probably won't live much more than another month.

But she made it to meet newborn Sara, even if the encounter has been somewhat different than I might have hoped earlier on.

"what a cute baby! is he a boy?"
"no, granny, this is Sara, your grand-grand-daughter, and she's called Sara, just like you…"
"Oh, how nice! This is a honor for me… you called her like me? how sweet of you!"

Of course we had told her this earlier, but she forgets things.
In a way it is nice to make her happy and give her this honor multiple times, but at the same time it isn't.

She does not understand what surrounds her anymore and most of the time she is in a dream-like state. Some old people have this, but their dreams are good, and they become just like young kids with visions that make them even happy at times.
But those dreams she's having are obviously bad ones, as she sighs and puffs and seems to be having a very hard time. And a lot of fear.
She is too afraid of letting go: after she dreamed a couple of times of my granddad and her mum (in the dream they were calling her to come and join with him in heaven), she is even afraid of falling asleep. And with little sleep she gets even more confused and depressed. And fearful. In a vicious circle.

She does have some moments of lucidity, and you can have short conversations with her, even if these moments tend to be shorter and shorter. And when they happen they even frighten her – I suppose because she realizes how she is the rest of the time.

But inevitably, five minutes later she will ask you again the same question:

"who is that cute baby I see over there?"
"dear granny, this is Sara, your grand-grand-daughter; she's called just like you"
"Oh how nice. This is a honor for me…."

She has lived so long, has had bad and good times, and done many good things, as well as many mistakes just like anyone does a lifetime.
Seeing her suffer is heart-breaking for us all.
I hope her suffering stops and her fears abandon her and that she might find her well deserved peace.

Amen.

I printed a tshirt for Sara with a baby-friendly Powershell cmdlet ("Get-Milk").
She already seems to be wondering what script she can write with it.

During the OpsMgr Health Check engagement we use custom code to assess the customer’s Management group, as I wrote here already. Given that the customer tells us which machine is the RMS, one of the very first things that we do in our tool is to connect to the RMS’s registry, and check the values under HKLM\SOFTWARE\Microsoft\Microsoft Operations Manager\3.0\Setup to see which machine holds the database. It is a rather critical piece of information for us, as we run a number of queries afterward… so we need to know where the db is, obviously

I learned from here http://mybsinfo.blogspot.com/2007/01/powershell-remote-registry-and-you-part.html how to access registry remotely thru powershell, by using .Net classes. This is also one of the methods illustrated in this other article on Technet Script Center http://www.microsoft.com/technet/scriptcenter/resources/qanda/jan09/hey0105.mspx

Therefore the “core” instructions of the function I was using to access the registry looked like the following

[Note: the actual function is bigger, and contains error handling, and logging, and a number of other things that are unnecessary here]

Therefore, the function was called as follows:
GetValueFromRegistry $RMS "SOFTWARE\\Microsoft\\Microsoft Operations Manager\\3.0\\Setup" "DatabaseServerName"
Now so far so good.

In theory.

Now for some reason that I could not immediately explain, we had noticed that this piece of code performing registry accessm while working most of the times, only on SOME occasions was giving errors about not being able to open the registry value…

When you are onsite with a customer conducting an assessment, the PFE engineer does not always has the time to troubleshoot the error… as time is critical, we have usually resorted to just running the assessment from ANOTHER machine, and this “solved” the issue… but always left me wondering WHY this was giving an error. I had suspected an issue with permissions first, but it could not be as the permissions were obviously right: performing the assessment from another machine but with the same user was working!

A few days ago my colleague and buddy Stefan Stranger figured out that this was related to the platform architecture:

• X64 client to x64 RMS was working
• X64 client to x86 RMS was working
• X86 client to x86 RMS was working
• X86 client to x64 RMS was NOT working

You don’t need to use our custom code to reproduce this, REGEDIT shows the behavior as well.

If, from a 64-bit server, you open a remote registry connection to 64-bit RMS server, you can see all OpsMgr registry keys:

If, anyhow, from a 32-bit server, you open a remote registry connection to 64-bit RMS server, you don’t see ALL – but only SOME – OpsMgr registry keys:

So here’s the reason! This is what was happening! How could I not think of this before? It was nothing related to permissions, but to registry redirection! The issue was happening because the 32 bit machine is using the 32bit registry editor and what it will do when accessing a 64bit machine will be to default to the Wow6432Node location in the registry. There all OpsMgr data won’t be in the WOW64 location on a 64bit machine, only some.

So, just like regedit, the 32bit powershell and the 32bit .Net framework were being redirected to the 32bit-compatibility registry keys… not finding the stuff we needed, whereas a 64bit application could find that. Any 32bit application by default gets redirected to a 32bit-safe registry.

So, after finally UNDERSTANDING what the issue was, I started wondering: ok… but how can I access the REAL “HLKM\SOFTWARE\Microsoft” key on a 64bit machine when running this FROM a 32bit machine – WITHOUT being redirected to “HKLM\SOFTWARE\Wow6432Node\Microsoft” ? What if my application CAN deal just fine with those values and actually NEEDs to access them?

The answer wasn’t as easy as the question. I did a bit of digging on this, and still I have NOT yet found a way to do this with the .Net classes. It seems that in a lot of situations, Powershell or even .Net classes are nice and sweet wrappers on the underlying Windows APIs… but for how sweet and easy they are, they are very often not very complete wrappers – letting you do just about enough for most situations, but not quite everything you would or could with the APi underneath. But I digress, here…

The good news is that I did manage to get this working, but I had to resort to using dear old WMI StdRegProvider… There are a number of locations on the Internet mentioning the issue of accessing 32bit registry from 64bit machines or vice versa, but all examples I have found were using VBScript. But I needed it in Powershell. Therefore I started with the VBScript example code that is present here, and I ported it to Powershell.

Handling the WMI COM object from Powershell was slightly less intuitive than in VBScript, and it took me a couple of hours to figure out how to change some stuff, especially this bit that sets the parameters collection:

Set Inparams = objStdRegProv.Methods_("GetStringValue").Inparameters

Inparams.Hdefkey = HKLM

Inparams.Ssubkeyname = RegKey

Inparams.Svaluename = RegValue

Set Outparams = objStdRegProv.ExecMethod_("GetStringValue", Inparams,,objCtx)

INTO this:

$Inparams = ($objStdRegProv.Methods_ | where {$_.name -eq "GetStringValue"}).InParameters.SpawnInstance_()

($Inparams.Properties_ | where {$_.name -eq "Hdefkey"}).Value = $HKLM

($Inparams.Properties_ | where {$_.name -eq "Ssubkeyname"}).Value = $regkey

($Inparams.Properties_ | where {$_.name -eq "Svaluename"}).Value = $value

$Outparams = $objStdRegProv.ExecMethod_("GetStringValue", $Inparams, "", $objNamedValueSet)

I have only done limited testing at this point and, even if the actual work now requires nearly 15 lines of code to be performed vs. the previous 3 lines in the .Net implementation, it at least seems to work just fine.

What follows is the complete code of my replacement function, in all its uglyness glory:

which can be called similarly to the previous one:
GetValueFromRegistryThruWMI $RMS "SOFTWARE\Microsoft\Microsoft Operations Manager\3.0\Setup" "DatabaseServerName"

[Note: you don’t need the double\escape backslashes here, compared to the .Net implementation]

Enjoy your cross-architecture registry access: from 32bit to 64bit – and back!

Last night at nearly 3:00am my daughter Sara was born.

During the beta of the Cross-Platform extensions and of System Center Operations Manager 2007 R2, the product team had promised to eventually release the SCX Providers'source code.

Now that this promise has been mantained, and the SCX providers have been released on Codeplex at http://xplatproviders.codeplex.com/ it should be finally possible to entirely build your own unsupported agent package, starting from source code, without having to modify the original package as I have shown earlier on this blog.
Of course this will still be unsupported by Microsoft Product support, but will eventually work just fine!
This is an extraordinary event in my opinion, as it is not a common event that Microsoft releases code as open source, especially when this is part of one of the product it sells. I suspect we will see more of this as we going forward.

Also, at R2 release time, some official documentation about buildilng Cross-Plaform Management Packs has been published on Technet.

Anyway, I have in the past posted a number of posts on my blog under this tag http://www.muscetta.com/tag/xplat/ (I will continue to use that tag going forward) which show/describe how I hacked/modified both the existing MPs AND the SCX agent package to let it run on unsupported distributions (and I think they are still useful as they show a number of techniques about how to test, understand and troubleshoot the Xplat agent a bit. In fact, I have first learned how to understand and modify the RedHat MPs to monitor CentOS and eventually even modified the RPM package to run on Ubuntu (which also works on Debian 5/Lenny), eventually, as you can see because I am now using it to monitor – from home, across the Internet – the machine running this blog:

Or even, with or without OpsMgr 2007 R2, you could write your own scripts to interact with those providers, by using your favourite Scripting Language.

After all, those experimentations with Xplat got me a fame of being a "Unix expert at Microsoft" (this expression still makes me laugh), as I was tweeting here:

But really, I have never hidden my interest for interoperability and the fact that I have been using Linux quite a bit in the past, and still do.

Also, one more related information is that the fine people at Xandros have released their Bridgeways Management Packs and at the same time also started their own blog at http://blog.xplatxperts.com/ where they discuss some troubleshooting techniques for the Xplat agent, both similar to what I have been writing about here and also – of course – specific to their own providers, that are in their XSM namespace.

Disclaimer

The information in this weblog is provided "AS IS" with no warranties, and confers no rights. This weblog does not represent the thoughts, intentions, plans or strategies of my employer. It is solely my own personal opinion. All code samples are provided "AS IS" without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability and/or fitness for a particular purpose.
THIS WORK IS NOT ENDORSED AND NOT EVEN CHECKED, AUTHORIZED, SCRUTINIZED NOR APPROVED BY MY EMPLOYER, AND IT ONLY REPRESENT SOMETHING WHICH I'VE DONE IN MY FREE TIME. NO GUARANTEE WHATSOEVER IS GIVEN ON THIS. THE AUTHOR SHALL NOT BE MADE RESPONSIBLE FOR ANY DAMAGE YOU MIGHT INCUR WHEN USING THIS INFORMATION. The solution presented here IS NOT SUPPORTED by Microsoft.

So Powershell v2 adds a nice bunch of Ws-Man related cmdlets. Let’s see how we can use them to interact with OpenPegasus’s WSMan on a SCX Agent.

PS C:\maint> test-wsman -computer virtubuntu.huis.dom -port 1270 -authentication basic -credential (get-credential) -usessl

cmdlet Get-Credential at command pipeline position 1
Supply values for the following parameters:
Credential

But we do get this error:

Test-WSMan : The server certificate on the destination computer (virtubuntu.huis.dom:1270) has the following errors:
The SSL certificate could not be checked for revocation. The server used to check for revocation might be unreachable.

The SSL certificate is signed by an unknown certificate authority.
At line:1 char:11
+ test-wsman <<<<  -computer virtubuntu.huis.dom -port 1270 -authentication basic -credential (get-credential) -usessl
+ CategoryInfo          : InvalidOperation: (:) [Test-WSMan], InvalidOperationException
+ FullyQualifiedErrorId : WsManError,Microsoft.WSMan.Management.TestWSManCommand

The credentials above have to be a unix login. Which we typed correctly. But we still can't get thru, as the certificate used by the agent is not trusted by our workstation. This seems to be the “usual” issue I first faced when testing SCX with WINRM in beta1. At the time I simply dismissed it with the following sentence

[…] Of course you have to solve some other things such as DNS resolution AND trusting the self-issued certificates that the agent uses, first. Once you have done that, you can run test queries from the Windows box towards the Unix ones by using WinRM. […]

and I sincerely thought that it would explain pretty well… but eventually a lot of people got confused by this and did not know what to do, especially for the part that goes about trusting the certificate.  Anyway, in the following posts I figured out you could pass the –skipCACheck parameter to WINRM… which solved the issue with having to trust the certificate (which is fine for testing, but I would not use that for automations and scripts running in production… as it might expose your credentials to man-in-the-middle attacks).

So it seems that with the Powershell cmdlets we are back to that issue, as I can’t find a parameter to skip the CA check. Maybe it is there, but with PSv2 not having been released yet, I don't know everything about it, and the CTP documentation is not yet complete. Therefore, back to trusting the certificate.

Trusting the certificate is actually very simple, but it can be a bit tricky when passing those certs back and forth from unix to windows. So let's make the process a bit clearer.

All of the SCX-agents certificates are ultimately signed by a key on the Management server that has discovered them, but I don't currently know where that certificate/key is stored on the management server. Anyway, you can get it from the agent certificate – as you only really need the public key, not the private signing key.

Use WinSCP or any other utility to copy the certificate off one of the agents.
You can find that in the /etc/opt/microsoft/scx/ssl location:

that scx-host-computername.pem is your agent certificate.

Copy it to the Management server and change its extension from .pem to .cer. Now Windows will be happy to show it to you with the usual Certificate interface:

We need to go to the “Certification Path” tab, select the ISSUER certificate (the one called “SCX-Certificate”):

then go to the “Details” tab, and use the “Copy to File” button to export the certificate.

After you have the certificate in a .CER file, you can add it to the “trusted root certification authorities” store on the computer you are running your powershell tests from.

So after you have trusted it, the same command as above actually works now:

PS C:\maint> test-wsman -computer virtubuntu.huis.dom -port 1270 -authentication basic -credential (get-credential) -usessl

cmdlet Get-Credential at command pipeline position 1
Supply values for the following parameters:
Credential

wsmid           : http://schemas.dmtf.org/wbem/wsman/identify/1/wsmanidentity.xsd
lang            :
ProtocolVersion : http://schemas.dmtf.org/wbem/wsman/1/wsman.xsd
ProductVendor   : Microsoft System Center Cross Platform
ProductVersion  : 1.0.4-248

Ok, we can talk to it! Now we can do something funnier, like actually returning instances and/or calling methods:

PS C:\maint> Get-WSManInstance -computer virtubuntu.huis.dom -authentication basic -credential (get-credential) -port 1270 -usessl -enumerate http://schemas.microsoft.com/wbem/wscim/1/cim-schema/2/SCX_OperatingSystem?__cimnamespace=root/scx

This is far from exhaustive, but should get you started on a world of possibilities about automating diagnostics and responses with Powershell v2 towards the OpsMgr 2007 R2 Cross-Platform machines. Enjoy!

Disclaimer

The information in this weblog is provided "AS IS" with no warranties, and confers no rights. This weblog does not represent the thoughts, intentions, plans or strategies of my employer. It is solely my own personal opinion. All code samples are provided "AS IS" without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability and/or fitness for a particular purpose.
THIS WORK IS NOT ENDORSED AND NOT EVEN CHECKED, AUTHORIZED, SCRUTINIZED NOR APPROVED BY MY EMPLOYER, AND IT ONLY REPRESENT SOMETHING WHICH I'VE DONE IN MY FREE TIME. NO GUARANTEE WHATSOEVER IS GIVEN ON THIS. THE AUTHOR SHALL NOT BE MADE RESPONSIBLE FOR ANY DAMAGE YOU MIGHT INCUR WHEN USING THIS INFORMATION. The solution presented here IS NOT SUPPORTED by Microsoft.

You know since the beta1 of Xplat I have been busy with modifying the Redhat management pack and monitor CentOS with OpsMgr. Now, CentOS is a distribution that is pretty similar to RedHat, so the RPM package just runs, and it is only a matter of hacking a modified MP.

I never went really further in my experiments, mostly due to lack of time… but then yesterday I got a comment to this older post asking about Ubuntu. Of course I know about Ubuntu, and have been using Debian-based distributions for years. I actually even prefer them over RPM-based distributions such as RedHat or SuSE (personal preference). Heck, even this weblog is running on Debian!

Anyway, I never really tried to see if one of the existing RPM packages for RedHat or SuSE could be modified to run on Ubuntu. I will eventually test this on Debian too, but for now I used Ubuntu which tends to have slightly newer packages and libraries, overall. The machine I tested on is a Ubuntu Server 8.04.2. Older/newer versions might slightly differ.

BEWARE THAT ALL THAT FOLLOWS BELOW IS NOT SUPPORTED BY MICROSOFT. It is only described here for EXPERIMENTAL (==fun) purpose. DO NOT USE THIS IN A PRODUCTION ENVIRONMENT.

So, you are warned. Now let’s hack it.

The first thing to do is to copy the Redhat agent’s RPM package off your OpsMgr2007 R2 server in the “usual” path “C:Program FilesSystem Center Operations manager 2007AgentManagementUnixAgents”. Let’s grab the RHEL5 agent, which is called scx-1.0.4-248.rhel.5.x86.rpm in R2 RTM.

First we need to CONVERT the RPM package to the DEB package format used by Ubuntu, by using the ALIEN package:

sudo apt-get update
sudo apt-get install alien
sudo bash
alien -k scx-1.0.4-248.rhel.5.x86.rpm –scripts
dpkg -i scx_1.0.4-248_i386.deb

The converted package will install… but the script execution will fail in a few places – most notably in the generation of the certificate, as it is not able to locate the right openssl libraries, as shown in the screenshot above.

If the libssl.so.6 file cannot be found, you might be missing the “libssl-dev” package, which you can install as follows:

apt-get install libssl-dev

But even if it is installed, you will find that the files are still missing. This is not really true: actually, the files are there, but on Ubuntu they have a different name than on RedHat, that’s all. You can therefore create hardlinks to the “right” files, so that they are aliased and get found afterwards:

cd /usr/lib
ln -s libcrypto.so.0.9.8 libcrypto.so.6
ln -s libssl.so.0.9.8 libssl.so.6

So now when installing the package, the certificate generation will work:

You are nearly ready to go. You have to start the service by using the init scripts – the “service” command is RedHat-specific, that will still fail.

/etc/init.d/scx-cimd start is the “standard” way of starting daemons from init on Unix.

But it still fails, as it seems that the init script provided in the RedHat package is really searching for a file called “functions” which is present on RedHat and on CentOS, which provides re-usable functions for startup scripts to include:

How do you fix this? I just copied the /etc/init.d/functions file from a CentOS box to my Ubuntu box.

I copied it via SCP from the CentOS box I have:

cd /etc/init.d

scp root@centos.huis.dom:/etc/init.d/functions .

You can probably also find and fetch the file from the Internet (both CentOS and RedHat should have accessible repositories with all the files in their distributions, since it is open sourced).

After you have the file in place, the init script will be able to include it, will find the functions it needs, and the daemon/service will now start (even if with minor errors I have not investigated for now, but that don’t seem to be causing troubles):

and here you can see it is finally running:

So let’s try to issue a few queries as shown in a previous posts:

IT WORKS!!!

But… there is a “but”: not all classes actually return instances and values just yet. Most notably the “SCX_OperatingSystem” class does not seem to return anything right awy. That is a very important class, because is the one we would use to first discover the Operating System object in the Management Packs. So we need to fix it. The reason why the class does not return anything, is that the SCX provider is looking into the /etc/redhat-release file to return what OS version/distribution the machine is running. And the file is obviously not there on Ubuntu.

On all Linuxes there is a similar file, called /etc/issue… which again, we can copy with the other name and trick the provider into working:

cd /etc

cp issue redhat-release

And NOW, the SCX_OperatingSystem Class also returns an instance:

The next step would be “cooking” an MP to discover Ubuntu. More on this on a later post (maybe). I did not test all classes and their implementation… you can try to poke at them by following the instructions and commands on my previous post here. But this should get you started.

Disclaimer

The information in this weblog is provided "AS IS" with no warranties, and confers no rights. This weblog does not represent the thoughts, intentions, plans or strategies of my employer. It is solely my own personal opinion. All code samples are provided "AS IS" without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability and/or fitness for a particular purpose.
THIS WORK IS NOT ENDORSED AND NOT EVEN CHECKED, AUTHORIZED, SCRUTINIZED NOR APPROVED BY MY EMPLOYER, AND IT ONLY REPRESENT SOMETHING WHICH I'VE DONE IN MY FREE TIME. NO GUARANTEE WHATSOEVER IS GIVEN ON THIS. THE AUTHOR SHALL NOT BE MADE RESPONSIBLE FOR ANY DAMAGE YOU MIGHT INCUR WHEN USING THIS INFORMATION. The solution presented here IS NOT SUPPORTED by Microsoft.
